SH7531 75mm Core NeodymiumHF Driver
NdFeB N40SH 75mm Core NeodymiumHF Driver
Specification:
Model | SH7531 |
Description | 75-core neodymium treble |
Outer diameter of magnetic steel | 131mm |
Diagonal screw hole | 100mm |
Throat diameter | 78mm |
Diaphragm material | Titanium |
Magnet | 131 magnetic |
Voice coil | 75-core copper-clad aluminium flat wire |
Height | About 5.5cm |
Magnetic steel material | NdFeB N40SH |
Rated Impedance | 8 ohm |
DC Impedance | 6 ohm |
Rated Power | 80 Watts |
Maximum power | 160 Watts |
Sensitivity | 108 dB/1W/1m |
Frequency range | 80-20KHz |
Place of Origin | Guangzhou, China |
Net Weight | About 2.5KG |
Features:
1. Metal terminal
The convenient and easy-to-understand connection mode of copper terminal brings more time-saving and labor-saving for installation
2. Installation is convenient and fast
well-designed of EVA, more suitable to the appearance of the product, highlighting the delicate taste
3. Nd-Fe-B magnetism
N40SH magnet steel makes the speaker more sensitive in power and better in timbre performance
