SP-SWIR85 IR Series Infrared Interactive Whiteboards
Exquisite craft IR Series Infrared Interactive Whiteboards
SP-SWIR85 IR Series Infrared Interactive Whiteboards Description:
IR Series Infrared Interactive Whiteboards use the world leading infrared multi-touch technology, with the perfect 10 touch and leading plag & play technology. IR series infrared interactive whiteboard use the 4:3 , 16:9 and 16:10 projection ratio, size is available from 85'' to 137''.
SP-SWIR85 IR Series Infrared Interactive Whiteboards Specification:
Model | SP-SWIR85 |
Physical Size | 85 inch |
Effective Size | 82 inch |
Display Ratio | 4:3 |
Physical Dimension | 1733*1230*30mm |
Packing Size | 1810*1310*90mm |
Net Weight | 23 KG |
Gross Weight | 15 KG |
Induction Technology | Infrared |
Induction Object | Finger, pen or untransparent object |
Resolution | 32768(W) * 32768(D) |
Calibration Deviation | <2mm |
Tracking Speed | >200inch/sec |
Cursor Speed | Max 300dots/sec |
Effective Touch Object | >=∅8mm |
Mouse Function | Single click, double click, right click |
Responding Speed | 15ms |
Consequent RS | 8ms |
Life | 100000hrs |
Voltage | DC 5.0V +- 5% |
Power Supply | USB |
Power Consumption | <=1W(200mA DC 5V) |
CPU | Pentium 800 ( 1G Hz (X86) CPU or above ) |
Memory | 1GB or above |
Hard disk | >=800mb |
Operation System | Windows 2000, Windows XP, Window Vista, Windows7, Windows 8.1, Windows10, Linux, Mac, Android |
Working Temperature | 30℃ - 60℃ |
Working Humidity | 0% - 95% |
Working Environment | Indoor / Outdoor |
Packing Details | Interactive Whiteboard *1; Software Disc *1; Whiteboard PEN *2; User Manual *1; Warranty Card *1; 5M USB *1; Wall-mount Suit *1 |
Place of Origin | Guangzhou, China |
SP-SWIR85 IR Series Infrared Interactive Whiteboards Features:
1. Perfect Writing Experience
2. Useful Hotkey
3. Exquisite craft, Excellent Experience
